Foundation analysis and repair design
Permanent structural crack bonding
Bowing wall stabilization systems
Written coverage on all repair work
Not every crack you find in your foundation wall signals a structural problem, but every crack deserves a professional evaluation because the consequences of misclassifying a structural crack as cosmetic are serious. Our assessment process includes measuring crack width at multiple points, documenting the orientation precisely, checking for horizontal displacement at the crack face, and reviewing the soil and drainage conditions outside the wall. The result is a categorization of the crack as cosmetic, water-entry, or structural -- each with a different repair recommendation.
The repair method matched to horizontal cracks depends on the degree of deflection and the construction type of the wall. For poured concrete walls with deflection below critical thresholds, a carbon fiber strap system bonded to the wall face with structural epoxy provides a tensile reinforcement layer that counteracts the lateral earth pressure. For block walls, carbon fiber straps bonded to a plate assembly anchored into the slab and rim joist provide the same function. In both cases the straps are virtually invisible after installation and do not require interior space to accommodate them.
Epoxy injection and polyurethane injection are the two primary methods for sealing and structurally repairing cracks in poured concrete walls. Epoxy injection produces a bond that is actually stronger than the surrounding concrete, making it the correct choice for cracks where structural re-bonding of the two faces is the goal. The process involves drilling a series of small ports along the crack at intervals calculated to ensure complete penetration, installing surface-mounted injection ports, sealing the visible crack face between ports with epoxy paste, and pumping two-component structural epoxy resin under low pressure until it fully fills the void and appears at adjacent ports. The resin cures within the crack to a solid, high-strength bond that is permanent and fully water-resistant.
Soil settlement beneath footings is an independent cause of foundation cracks that requires evaluation separately from the wall repair itself. When soil compresses or washes out from beneath a footing, that section of the foundation wall loses its support and the wall may develop diagonal cracks as the unsupported section deflects downward. In these cases, crack injection addresses the symptom while leaving the root cause unresolved. Our assessment includes a review of grading, drainage, and visible footing conditions to identify signs that settlement is active. Where settlement is a factor, we coordinate the repair approach to address both the crack and the soil condition that created it, preventing recurrence after the crack is sealed.
From hairline seepage cracks to structural horizontal cracking, we have the right fix.
Every epoxy injection job is documented with before-and-after photos and a report of injection pressures and resin volumes consumed to verify full crack penetration.
Expanding polyurethane resin fills irregular crack voids completely, including geometry that epoxy cannot fully penetrate, and cures to a flexible seal that tolerates minor seasonal wall movement without reopening.
We calculate strap spacing and quantity based on the measured deflection, wall height, and soil pressure conditions at each job so the reinforcement is engineered for your specific wall rather than generically applied.
Wall anchors can be tightened over time as the soil condition allows, potentially restoring some of the original wall plumb position without excavation or more invasive structural work.
We repair stair-step cracks by tuck-pointing the affected mortar joints with a compatible mortar mix matched to the existing wall, reinforcing corner crack locations, and applying a crystalline waterproofer to the repaired area to prevent water intrusion at the newly bonded joints.
The joint where a poured concrete wall meets the footing is a construction cold joint that is prone to opening as the wall and footing settle and move at slightly different rates, creating a direct water pathway into the basement.
Crack mapping, moisture readings, and wall plumb measurements are documented in a written report that accompanies your quote.
Written scope defines every material, method, and warranty term before you approve any work so there are no surprises on the invoice.
Carbon fiber installations include verification of bond strength and strap spacing against the engineered design before the job is signed off.
A written warranty is issued on project completion, covering the repair against reoccurrence under normal conditions for the warranty period stated in your contract.
We had a 14-foot horizontal crack in our block wall that two other companies dismissed as not serious. JCB Waterproofing and Construction came in, took actual measurements, and explained exactly why it needed carbon fiber straps immediately. The repair looks clean and the wall has not moved since.
I was told by two contractors that my diagonal cracks were just cosmetic. JCB Waterproofing and Construction measured the crack width at three points and showed me they were widening. The epoxy injection repair was completed cleanly and the cracks have been stable for over a year.
I appreciated that they did not try to upsell me on a full drain system when crack injection was the right fix for my situation. They solved the actual problem and the repair has held completely.
JCB Waterproofing and Construction serves Painesville homeowners with certified epoxy injection, polyurethane sealing, and carbon fiber reinforcement. Call for your free structural assessment today.
